Corrugation Machine

Corrugation machine is used in manufacturing process for Corrugated sheets or rolls. There are Two types of corrugation machine available on paperekart fingerless corrugation machine and double profile corrugation machine Designed for corrugation applications, this machine is made of high quality raw materials.

Single Facer Corrugation Machine Fingerless Single Facer Corrugation Machine Corrugation Machine Double Profile Corrugation
62’’ Congzhou Single Facer Corrugation Machine

Price: 750000 - 800000
Brand: Congzhou
Machine No: 20230326001
Size: 62’’
Mfg Yr: 2016
Location Ahmedabad, Gujarat, India
Description 62’’machine with 14’’ diameter roll. & shaft less reel stand. very rarely used _total Pnumatic control on pressure glue and brake Read More

36 ravi Single Facer Corrugation Machine

Price: 250000 - 300000
Brand: ravi
Machine No: 20230326002
Size: 36
Mfg Yr: 2014
Location Rajkot, Gujarat, India
Description Read More

63 Inch Chinese Fingerless Single Facer Corrugation Machine

Brand: Chinese
Machine No: 20230517001
Size: 63 Inch
Mfg Yr: 2021
Location Tundla, Uttar Pradesh, India
Description 63 inch fingerless corrugation machine .. almost brand new condition... Read More

65 Inch Chinese Fingerless Single Facer Corrugation Machine

Brand: Chinese
Machine No: 20230517002
Size: 65 Inch
Mfg Yr: 2021
Location Tundla, Uttar Pradesh, India
Description 65 inch fingerless corrugation almost brand new Read More

XinGunag Wj300-2500 Corrugated Board Production Line Corrugation Machine

Brand: XinGunag Wj300-2500 Corrugated Board Production Line
Machine No: 20230829003
Size: 0
Mfg Yr: 2023
Location Vapi, Gujarat, India
Description WJ300-2500-Ⅱtype five layer corrugated paperboard production line Specification Equipment name QTY Remark ZJ-V6B Hydraulic shaftless mill roll stand 5set Spindle￠270mm，hyperbolic heavy rocker, toothed chuck , multi-point brake, hydraulic drive lifting, panning left and right on the middle. Pneumatic ejector. YXC Hydraulic pressurePaper system 10set Double groove width 10m. guide rail length and the ground level, on the double position paper design, hydraulic clamp for paper, paper unloading hydraulic push rod save manpower, hydraulic motor traction feeding trolley. JZJ-A Automatic splicer 5set Automatic splicer keep corrugating cardboard assembly line uninterrupted work，Reduce paper consumption，Greatly improve productivity.Maximum speed 300m/min RG-1-10B Top paper preheat cylinder 2set Roller￠1000mm, including pressure vessel certificate. Adjust the wrap angle electrically. The wrap angle can adjust the heated area of the paper within 360°. The angle of wrap is automatically adjusted according to the speed of the vehicle, the angle of the wrap angle is displayed on the touch screen, and the parking automatically returns to zero to facilitate paper penetration. RG-1-10B Top paper preheat cylinder 2set Roller￠1000mm, including pressure vessel certificate. Adjust the wrap angle electrically. The wrap angle can adjust the heated area of the paper within 360°. The angle of wrap is automatically adjusted according to the speed of the vehicle, the angle of the wrap angle is displayed on the touch screen, and the parking automatically returns to zero to facilitate paper penetration. SF-500A Multi-cassette positive pressure single facer 2set Main corrugating roller￠500mm，corrugating roller group flute quick change.corrugated roller with spraying tungsten carbide dealing.with maintenance-free airbag loading,PLC automatic control glue, HMI touch screen, Breaks automatic parking relief. DY-C Electric hydraulic roller change forklift 1set Large capacity battery, power walking, hydraulic lift, centralized control. MK－500A Corrugating roller quick change Module 1set Corrugating roller diameter:500mm，with tungsten carbide dealing，Modules including：Both ends of the shaft seat、bearing、steam element、Suction box、Pneumatic components assembly. RG-3-1060 Triple preheater 1set Roller￠1000mm, including pressure vessel certificate. Adjust the wrap angle electrically. The wrap angle can adjust the heated area of the paper within 360°. The angle of wrap is automatically adjusted according to the speed of the vehicle, the angle of the wrap angle is displayed on the touch screen, and the parking automatically returns to zero to facilitate paper penetration. GM-35 Doubleglue machine 1set Glue roller diameter 320mm。Frequency motor drive, PLC control. Glue quantityPCL automatic adjustment，HMI touch screen display. TQ-A Conveyor bridge 1set 200mm main beam channels, independent inverter motor drive pull paper feed, adsorption tension.Electric correction. XG-JP Automatic correction 1set No power correction model save energy.High precision sheet correction. Paper width change does not require any adjustment Full width infrared detection curtain。Reduce paper waste generated tear。reduce the waste of paper edge not to precision. SM-E Double facer 1set The frame is 400 mm national standard channel steel, chrome plated hot plate 600 mm *18 pieces, the entrance uses arc-shaped hot plate to make the facial paper heat up extremely quickly, and the design structure of the whole pressure plate is touched. PLC automatically controls the pressure plate. The upper and lower belts have automatic deviation correction, temperature display, and frequency conversion motor. The PID automatic temperature control system is used to link the three-layer and five-layer automatic control of the number of temperature hot plates, which is highly efficient and energy-saving. Temperature Control System 1set The PID automatic temperature control system is connected with the production tube, and the number of temperature heating plates is automatically controlled by the three and five layers, which is highly efficient and energy saving. NC-QD Automatic multifunctional cutting machine 1set Servo control cuts to quickly remove waste cardboard; servo control for smooth paper feeding and conveying Collecting trolley 1set Stainless steel paper tray 1set NCBD NC thin blade slitter scorer 2set Tungsten alloy steel, seven knives twelve lines，zero-pressure line type. Schneider servo computer automatically discharge knife, suction outlet width automatically adjusted.Closed electric control box, plus air conditioning and dehumidification. Automatic waste suction system 1set Including: four sets of waste suction port pneumatic switching system, 12 meters stainless steel waste suction hose, 12 meters metal waste suction pipe, 22KW paper shredding fan and controller, etc. NC-35D NC cutter helical knives 1set Full AC synchronous servo control, energy storage brake, spiral knife structure, helical gear drive, hollow knife shaft, lubricating oil pressure protection, 10.4-inch touch screen display. Closed electric control box, plus air-conditioning and dehumidification。 Automatic waste board machine 1set Automatically eliminate the cardboard joints for changing sheets that are inserted and cut by the cross-cutting machine, and servo-control cardboard conveying. NC-DLM Automatic large gantry stacker 1 set Servo drive platform lift,foursections of frequency transmission, automatic points in batches, automatic stacking discharge, imported high-strength belt output,out paper side standard transport aircraft. SG Production Management System (complex) 1set Improve the automation of production lines，easy to operate.reduce consumption,Improve the utilization of the base paper，save costs. Automatic control production line，stable quality cardboard.Increase the average speed，Increase productivity.Automatic statistics production，Easy to keep control of the production line, improve efficiency. ZJZ Glue station system 1set Customers -owned pipeline.Glue configuration is composed by carrier tank、main tank、storage tank、and send plastic pump、back plastic pump. QU Gas source system 1set Gas source is prepared by the customers. ZQ Steam system 1set Steam system components used in all GB valves.Including rotary joint,upper and lower dispenser.traps，pressure table and so on.Customer-owned boilers and pipes. DQ Electrical control cabinet system Electric control system: Adsorption single-sided machine, drive unit, double-sided machine, and gluing machine all use frequency conversion motors, Siemens frequency conversion control system. The operation interface is simple and convenient. The speed display control cabinet is equipped with the speed display of each unit, the unit call, and the emergency stop function. The main contactor adopts Germany's Siemens SIEMENS brand-name products, the main frequency conversion motor adopts Siemens Bader brand, the main bearing adopts Japan NSK, and the main inverter and PLC adopt Siemens. Read More

J.S Machine JETS400 CORRUGATOR Corrugation Machine

Brand: J.S Machine JETS400 CORRUGATOR
Machine No: 20230830001
Mfg Yr: 2023
Location Vapi, Gujarat, India
Description Integrated design, reflecting the overall, environmental and safety design concept; suitable temperature and pressure-saving energy-saving steam system, making full use of double-flash evaporation; Belt-type single-watt unit: Positive pressure guide paper in the rubber coating section to reduce downtime recovery time; Intelligent control of tension according to the order base paper formula; Tile roller and pressure belt pressure adaptive base paper, no need for gap adjustment; High speed machine of transport paper: Constant paper tension control of the base paper, servo control for winding, unwinding, and buffer paper for paper picking; The constant tension control function of the base paper is highly efficient and has a wide range of adaptability. Width Series: 3300mm Design Speed: 400m/min Change Order Speed: 300m/min (dry section) Staff: 4 people (five-layer line) Gram Weight: 110-300g/m2 Tensile Strength: 5.5kgf/cm (minimum) Read More

N/A BHS Double Profile Corrugation

Brand: BHS
Machine No: 20231117001
Size: N/A
Mfg Yr: 2022
Location Vapi ...
Description INTRODUCTION: Flawless bonding, drying and transport. The Double Facer from BHS Corrugated does it all – from micro-flute to heavy triple-corrugated board. How productive your corrugator is largely depends on the performance of your Double Facer, especially in markets with a high proportion of double flutes. This factor is generally what determines the pace at which a corrugator runs. That is why, in developing the Double Facer, BHS Corrugated opted to prioritize speed, laying the groundwork for achieving maximum speeds with double flutes and even heavier triple-corrugated board. Some Functions Of These Machine Are As Follows: Platerol loading system: The perfect combination of strengths The Platerol loading system combines the advantages of rolls and pressure shoes for highly efficient heat transfer and optimal web connections. The customized features ensure consistently good bonding by providing the ideal combination of line pressure and surface pressure. This makes it possible to avoid caliber losses even with narrow working widths. As a result, there are fewer rejects, even with fast quality changes. The system is fully automated and equipped with a number of specific speed and safety features. It can be operated from the control console as well as directly from the control station. Technical Features: For excellent user-friendliness The Machine Control Center (MCC) forms the interface between the operator and the machine. The MCC monitors the system. Its integrated features, including an operating hours counter and maintenance system, enables it to also perform complex error diagnostics. All information about the current state of the machine is compiled and processed here and represented structurally. So, information is clearly presented and instantly available to the operator. The MCC also allows you to test, modify and save settings. The special belt boasts even more enhanced features like higher wear resistance and excellent drying performance. In addition, it ensures the optimal flatness of your corrugated board. The MCC also comes with a permanently integrated cleaning program. Pressure Shoes And Hotplates: Features for precise heating The high, consistent surface pressure of the pressure shoes facilitates excellent heat transfer between the hotplates and corrugated board. This significantly enhances the effectiveness of the heat sections. An even load across the working width prevents the corrugated board from being pressed together. The hotplate is mounted on a stable base. This makes it possible to ensure that the hotplates are in a flat position in all operating states. Heat is transmitted exclusively through this plate, allowing for the fastest possible reactions to production changes. The result – much less production waste! Thanks to the large front doors and height-adjustable loading system, the hotplates practically clean themselves. Dual Boost Technology: Innovative high technology for your Double Facer The performance of your Double Facer is a critical factor for the productivity of your entire corrugator: this applies in particular to achieving the best possible maximum and average production speeds. For physical reasons, production speeds are often severely limited in this area of the corrugator. Whether you are running double or triple wallgrades: investment in proven technical developments on the Double Facer will always sustainably increase the performance of the entire corrugator. With “DualBoost", BHS Corrugated has developed a specific module for the critical infeed of the Double Facer, to achieve a quick return by significantly increasing the production speed. The many years of market leadership and the pronounced innovation potential that BHS Corrugated can bring to bear with the aim of maximum economic efficiency for the operators of corrugated box plants is impressively reflected in this exclusive additional module. The name DualBoost already gives a clear indication of how the module works. "Dual" refers to the clever combination of heating the lower top web liner in a functional unit with steam moistening of the upper, single-wall web. The high efficiency of the unit results in a "boost" of the gluing process as far as double-wall or heavier grammages are concerned. The optimum positioning of the DualBoost in the specially optimized infeed stand maximizes the effectiveness of the process, as the webs finally run together. The so-called "double kiss effect" is also significantly reduced by the special web guide, which leads to just before the gluing point. This leads to a constantly even gluing across the working width without edge gluing problems, again, the optimal design of the infeed stand is decisive for this. The two independent functions - liner heating / corrugated web moistening - can be individually controlled depending on speed and board grade. The outflowing steam, which is directed in the running direction of the corrugated board, conditions the paper and starch at the flute tips prior to bonding with the liner. At the same time, the inner volume of the corrugated board is filled with saturated steam as an energy carrier, thus increasing the energy inside the corrugated board. This leads to faster heating and conditioning, which further reduces the risk of the corrugated board drying out. The spraying unit sprays saturated steam where it is really needed. This helps to save energy permanently and reduces energy losses. The intelligent control system ensures that the amount of steam flowing out is not only in relation to the line speed, but also in accordance with the current paper width being run. The openings of the spray unit are arranged in such a way that they are maintenance-free. This ensures minimal maintenance and cleaning of the entire system. The increased energy level of the steam/air volume introduced into the web shortly before the gluing point results in a much more effective heat transfer. In this way, the use of DualBoost technology enables the adhesive strength of the webs to be increased by up to ten percent. DualBoost units installed have resulted in production increases averaging up to 30 m/min with double wall qualities and up to 20 m/min with triple wall. Machine Safety: The Double Facer from BHS Corrugated meets the requirements of EN 1010-1 and EN 1010-5, the industry standard of the European CE Machinery Directive. Read More

fingerless single facer corrugation machine only
1400 x 2500 mm Virdi Brothers Fingerless Single Facer Corrugation Machine

Price: 1250000 Onwards.. (Negotiable)
Brand: Virdi Brothers
Machine No: 20220122002
Size: 1400 x 2500 mm
Mfg Yr: 2022
Location Mumbai, Maharashtra, India
Description Features: 1) Drive reducer using oil bath lubrication , reducing noise, card and drive,isolated power supply (optional) 2) On tile roller, pressure roller, glue roller lift, have been pneumatic control 3) Using vacuum adsorption , leading paper with air conditioning , maintain the stability of the state of corrugated type stare blankly at high speed 4) Corrugated board, pressure roller bearing adopts high temperature fabricating grease. 5) Using automatic cycle for rubber coating department. 6) Corrugated roller is made of high quality alloy steel after heat treatment the surface Manual or electric insulation glue device. 7) Glue the downtime can be independent running or not running in two ways. Usage/Application Commercial Brand/Make VBM Effective Width 1400-2500 mm Power Source Electric Roller Size 320 (360)m Frequency 50 Hz Volatage 280 V Country of Origin Made in India Speed 120-150 m/min Automation Grade Automatic Read More

double profile corrugation machine online on Pape
52 Inch Virdi Brothers Double Profile Corrugation

Price: 1400000 Onwards.. (Negotiable)
Brand: Virdi Brothers
Machine No: 20220131004
Size: 52" Inch
Mfg Yr: 2022
Location Mumbai, Maharashtra, India ...
Description Features: 1) Size: 62" & 72" 2) Two sets of flute rollers, one set of narrow fluterollers and another set of broad flute roller. 3) Hydraulic system for smooth and noiseless interchanging of flute rollers within few minutes. 4) Common gum unit & Common pressure roller. 5) Increase in the production by cutting down thechange over time of flute rollers. 6) Hydraulic Twin shaft reel stand helps in fastoperation and save time. Usage/Application Commercial Brand/Make VBM Automation Grade Automatic Frequency 50 Hz Voltage 280 V Country of Origin Made in India Size 52" Inch Power 1 HP Read More

single facer corrugation machine online at PaperEk
62 Inch Virdi Brothers Single Facer Corrugation Machine

Price: 950000 Onwards.. (Negotiable)
Brand: Virdi Brothers
Machine No: 20220201004
Size: 62" Inch
Mfg Yr: 2022
Location Mumbai, Maharashtra, India
Description Features: 1) Drive reducer using oil bath lubrication , reducingnoise, card an drive, isolated power supply (optional) 2) On tile roller, pressure roller, glue roller lift,have been pneumatic control 3) Using vacuum adsorption , leading paper with airconditioning , maintain the stability of the state of corrugated type stareblankly at high speed 4) Corrugated board, pressure roller bearing adoptshigh temperature fabricating grease. 5) Using automatic cycle for rubber coatingdepartment. 6) Corrugated roller is made of high quality alloysteel after heat treatment on the surface Manual or electric insulation gluedevice. 7) Glue the downtime can be independent running or notrunning in two ways. Usage/Application Commercial Speed 120 - 150 m/min Brand/make VBM Automation Grade Automatic Frequency 50 HZ Voltage 280 V Motor HP 1 HP Country of Origin Made in India Effective WIdth 1400-2500 mm Roller Size 320 (360)mm Read More
