Characteristics
1.Driving by V-ribbed belt,ensure smooth and accurate running.
2.Inverter driving,stable and power saving.
3.Use electric adjust,easy operate.
4.Automatic continuous feeding,use multiple belt with vibrating motor ,to keep the feeding stable.
5.Automatic counting and kicking,quantity can preset.
6.Conveyer pressure adjustable according to the box to ensure best quality.
7.The machine is configured with remote control，Remote troubleshooting, update the program.
Main technical parameter
|
Model
|
HF-GBL1100
|
|
Suitable material
|
Card board210gsm-850gsm,E,F,N flute corrugated board
|
|
Max method
|
Automatic continuous feeding
|
|
Max mechanical speed
|
400m/min
|
|
Overall dimension
|
19700*1950*1900mm
|
|
Weight
|
11.5T
|
|
Glue type
|
Cold glue
|
|
Power consumption
|
30.5KW,380V 50HZ
|
|
Compressed air
|
6 bar,10 m³/h,60 L
|
|
Inching speed
|
30 m/min
|
