Introduction:
Computer type automatic glue machine is consist of three parts, which is paper feeding part, gluing and folding part and counting and stacking part. Automatic Computer adjustment paper feeding / fold and glue. Automatic counting and stacking output. Wall board thickness 40mm. The speed can reach 150-200 pieces per minute. Advanced and reasonable structure design and manufacture, it demands for cultural level of operators is not high, and operators will be able to handle all operating procedures in one or two working days, and protect the safety of operating personnel. Delta touch scree, PLC, Inverter, China Famous Brand bearings.
Specification:
Model
|
YK-ZXJ 2800 |
| Max. Cardboard |
1200*2400mm |
| Mini. Cardboard |
300*800mm |
| Diemensions |
15500×3000×1600mm |
| Power required |
12 kw |
Speed
|
150-200 Pcs/min |
| Voltage |
220V/380V/415V |
